IS-160S/IS-180S/IS-200S Photovoltaic grid connected micro inverter household power generation inverter European standard
【size：IS-160S/IS-180S/IS-200S 】
♦ Safe and efficient
PPS： Aluminum alloy shell is dustproof, waterproof, and fireproof
Conversion rate 96.7%+
Plug and play, easy to install
♦ Simple and flexible
Unrestricted by space, can be installed anywhere
Adjust excess battery and conversion through mobile app/PC web control
♦ Intelligent monitoring
Component level monitoring makes operations more precise, efficient, and reduces costs
Fanless design, no noise pollution
♦ User-friendliness
EMC meets the requirements of household appliances
♦ Quick shutdown function
♦ Plug and play, easy to install
♦ 1 MPPT, conversion rate 96.7%+
♦ Built in WiFi, can directly connect to apps
♦ IP67， Can be used outdoors
♦ 12 year warranty, extendable to 25 years
Direct current input terminal (DC)
| PRODUCT MODEL |
IS-160S
|
IS-180S | IS-200S |
| Adaptive component power range (W) | (240~405+)*4 | ( 320~540+)*4 | ( 400~670+)*4 |
| MPPT voltage range (V) | 16-60 | 16-60 | 16-60 |
| Maximum input voltage (V) | 60 | 60 | 60 |
| Starting voltage (V) | 22 | 22 | 22 |
| Maximum input current (A) | 16*4 | 16.5*4 | 17*4 |
| Maximum input short-circuit current (ISC) (A) | 25 | 25 | 25 |
| MPPT quantity | 4 | 4 | 4 |
Communication output terminal (AC)
| Rated output power (W) | 1600 | 1800 | 2000 |
| Rated output current (A) | 6.96 | 7.83 | 8.70 |
| Nominal output voltage (V) | 220/230/240 | 220/230/240 | 220/230/240 |
| Nominal output frequency (Hz) | 50/60 | 50/60 | 50/60 |
| Power factor (default/adjustable) | 0.99 / 0.90 leading...0.90 lagging | 0.99 / 0.90 leading...0.90 lagging | 0.99 / 0.90 leading...0.90 lagging |
| Total harmonic distortion | ＜3% | ＜3% | ＜3% |
Conversion efficiency
| Peak Efficiency | 96.70% | 96.70% | 96.70% |
| Nominal MPPT efficiency | 99.90% | 99.90% | 99.90% |
| Nighttime self consumption electricity (mW) | ＜50 | ＜50 | ＜50 |
Mechanical data
| Working temperature range (℃) | -40±65 |
| Storage temperature range (℃) | -40±85 |
| Altitude (m) | 4000 |
| Noise (dB) | ＜20 |
| Shell protection level | IP67 |
| Cooling method | natural cooling |
| Dimensions (width * height * depth mm) | 192*208*35 |
| Weight(kg) | 1.95 |
